- SKU: PM3121-W
- A Interchanges: 064296, 469887, 591060, 591299, 64057, 689500E020, 689500E021, 68950-0E021, 689500E110, 689500E120, 6895049185, 68950-49185, 6895049195, 68950-49195, 6895049205, 68950-49205, 6895049215, 68950-49215, 689600E02, 689600E020
- Body Connection: Bracket 2 Bolt Holes
- Compressed Length B [in]: 13.07
- Custom Qty: 2
- Cylinder Diameter (MM): 22
- End Fitting Size: Other
- End Fitting Type: Other
- Extended Length A [in]: 20.43
- Finish: Black
- Force (Lbs): 145
- Force Newtons: 645
- Include In Length Search: Yes
- Include In mmty Search: Yes
- MSDS Info: Click Here to Download the Lift Supports Depot MSDS Sheet.
- Manufacturer: Lift Supports Depot
- Manufacturer Logo: portal.liftsupportsdepot.com/images/nextopia/liftsupportlogosmall.gif
- Name (Fitment): Made by Lift Supports Depot Fits the Liftgate | PM3121
- Quantity Sold As: Each
- Rod Diameter (MM): 10
- Shaft Connection: Bracket 2 Bolt Holes
- Stroke C [in]: 7.36
- Vehicle Location: Liftgate
4 Reviews Hide Reviews Show Reviews
-
lifts
great product
-
Rear gate lifts for 2009 Lexus
Very quick delivery and easy install. Gate lift to OEM height, protecting my head. Still the first day, but 5 stars to date.
-
Fits Our RX Lexus Nicely and Seems to Work Fine
Installed on a 2007 RX350 with power liftgate. Installation was a breeze with no issues. After installation, the liftgate opened correctly (manually) and was no problem to close (manually). Using the power option, the motor did seem to slow a bit when trying to close hatch with the new struts. However, it successfully closed without issue. Of course opening with the power liftgate was not a problem. Since this is the heat of the summer, I have no indicator if these will behave the same in cold weather. I also cannot comment on the longevity of these struts. Although, as I mentioned, installation was easy, and so far, operation is similar or the same as OEM. Obviously, the price for these is MUCH less expensive than buying the Toyota replacements.
-
Lifts for Lexus lift gate
These fit perfectly. The instructions and associated warnings were adequate. For Lexus owners use caution in product selection. There are models built in the US, Canada and Japan. At first glance they appear the same but there can be differences. Manufacturing plant is on a sticker in driver's door sill. Check the lift's dimensions on the vehicle and compare to Lift Supports specifications. On the factory install there is a left and right part number. For after-market there is a single part (number). The left / right numbering is for the robotic factory install and the part's orientation. So take your time choosing the required lift.
- 2007-2009 Lexus RX350 Base Sport Utility 4-Door Liftgate-With & Without Power Liftgate
- 2007-2009 Lexus RX400h Base Sport Utility 4-Door Liftgate-With & Without Power Liftgate
- 2008-2009 Lexus RX450h Base Sport Utility 4-Door Liftgate-With & Without Power Liftgate
